Link Remover icon: white scissors on a red square

Link Remover

Deletes links of the link types you choose from a whole module or a selection, with a preview and a confirmation before anything goes.

Supported products: RM = IBM Engineering Requirements Management DOORS Next (Requirements Management)Links and traceabilityChanges dataVersion 1.63 · released 2026-11-19

Works in
IBM DOORS Next module
Supported products
  • RM IBM Engineering Requirements Management DOORS Next (Requirements Management)
Version
1.63
Released

What it is and why it exists

Traceability is only useful when it is correct. After a reorganization, a failed import, a change of the traceability model or a test with the wrong link type, modules end up with hundreds of links that must be removed. In the standard interface every link is deleted separately, artifact by artifact.

Link Remover cleans up traceability in bulk and safely: you choose the link types and the direction, see exactly which links are found, and remove them in one controlled run.

Problems it solves

  • Hundreds of obsolete or wrong links after imports, migrations or a change of the traceability model.
  • Deleting links one by one, which is slow and easy to get wrong.
  • Uncertainty about whether links live in the module context or on the base artifacts, and what removing them affects.
  • No record of which links were removed.

Benefits

  • Targeted cleanup: only the chosen link types, in the chosen direction (outgoing, incoming or all).
  • Safe by default: only links in the module context are removed unless you explicitly include links on base artifacts, and that option switches itself off after every run.
  • Preview: the number of links and every link per artifact are shown before removal.
  • A confirmation that names the number of links, the artifacts and the link types.
  • Long runs under control: progress, Stop, a list of links that could not be removed with Retry, and an Excel change report.

How to use

  1. You1Tick the link types and the direction
  2. Widget2Find links: lists every linkIf needed: Or Selection: artifacts selected in DOORS Next
  3. You3Remove now, check and confirm
  4. DOORS Next4Links deleted after confirmationIf needed: Some failed: Retry
  5. Result5Result with the Log in Excel
  1. Under Link types, click Change, tick the link types to remove and choose the Direction: All directions, Outgoing or Incoming. The list comes from the link types defined in your project.
  2. Optionally tick Find and remove links in the module and on base artifacts, then click Done.
  3. Under Remove, choose Whole module (open a module first) or Selection (artifacts selected in DOORS Next) and click Find links. Nothing changes yet: the result shows how many artifacts were checked, how many have these links and how many links will be removed, and Links lists them.
  4. Click Remove now, read the confirmation and confirm with Remove N links.
  5. The result shows the links removed, those on base artifacts, the artifacts changed and any failures, with Retry. The Log saves the change report to Excel.

Good to know

  • Links on base artifacts disappear in every module that reuses the artifacts; use this option deliberately.
  • A link between two artifacts of the same module is removed once, not twice.
  • Always work in a change set: discarding it is the only way to bring removed links back.
  • On the whole module, Remove now also works without a search: it removes the links of the chosen types in a single pass, after the same confirmation.
  • Outside a module, the widget works on the artifacts selected in DOORS Next.
  • On very large modules you can Stop, reload the page and click Continue from … to go on from the next artifact.

What's new in version 1.63

· Change titles are published in English.

  • New code really loaded
