Style Cleaner
Removes the fonts, colours and margins that Word and other tools leave in requirement texts, so every artifact looks the way DOORS Next intends.
Video

The video opens from YouTube (youtube-nocookie.com) only after you click it.
What it is and why it exists
Requirements rarely start their life in DOORS Next. They are pasted from Microsoft Word, imported from ReqIF or Excel, or copied from emails. Each of these sources brings hidden formatting along: fonts, font sizes, colours, line spacing and margins that are stored inside the text of the artifact.
The result is a module where every paragraph looks slightly different, documents generated from it look unprofessional, and text sometimes becomes unreadable in another theme. Removing this formatting by hand means opening every artifact in the rich text editor. Style Cleaner does it for a whole module in one pass.
Problems it solves
- Specifications with mixed fonts, sizes and colours after imports from Word, Excel or other tools.
- Published documents and reports that inherit the foreign formatting.
- No way in the standard interface to see which artifacts carry hidden formatting, or how much.
- Cleaning by hand takes hours on large modules and is easily left half done.
Benefits
- A consistent look for every artifact, in DOORS Next and in every document generated from it.
- You choose what goes: inline styles only, or also old attributes such as alignment and width and formatting tags such as bold, underline or font.
- You see it before it changes: the widget lists the artifacts that contain formatting, and what it found most, before it touches anything.
- Whole modules in one run, without the limit of 200 artifacts that selections have.
- Only formatting is removed. Text, tables, lists, images and links stay exactly as they were.
- Evidence: an Excel change report records every cleaned artifact.
How to use
- You1Open a module and choose in Settings what to remove
- You3Check the list and each artifact's styles
- DOORS Next4Remove styles from all of themIf needed: Only some: select them and use Selection
- Result5Change report in Excel
- Open a module. In Settings, click Change and tick what to remove: attributes such as
style,classoralign, and formatting tags such as<b>,<u>or<font>, in six groups with Select all. Each item has an (i) that says what it is. Click Done. - Choose Whole module under Clean and click Find. Nothing changes yet: the widget shows how many artifacts it checked, how many contain what you ticked, how many styles and tags they hold and what it found most.
- Click any artifact in the list to see exactly which formatting it carries, element by element, and Show in module to jump to it.
- Click Remove styles, read the short confirmation and click Remove styles in it. A progress card shows the run, and you can Stop at any moment.
- To clean only some artifacts, select them in DOORS Next and choose Selection · N: the widget checks them at once. Then click Remove styles and confirm.
- At the end the result shows how many artifacts were cleaned and how many styles and tags were removed. Click Log to download the change report in Excel.
Screenshots
1240 artifacts checked: 131 carry what is ticked in Settings, with what was found most 2Settings: tick the attributes and formatting tags to remove; only style="" is ticked at first 3One artifact opened: the exact formatting it carries, element by element 4Confirmation before the styles and tags are removed from all 131 artifacts 5Styles and tags removed: the module is clean and the change report is in the Log 6Selected artifacts are checked at once: 3 of 6 carry styles or tags
Good to know
- Run Style Cleaner in a change set, so you can review the result before delivering it.
- Highlight in module selects all affected artifacts in DOORS Next without changing them, for example to review them first.
- Typical moments to use it: right after an import, before a review, and before publishing a document.
- Without an open module (in a collection or folder view) Whole module is locked and the widget works on the selected artifacts only.
- On very large modules the browser can get slow, because DOORS Next keeps every artifact it reads in memory. Stop the run, reload the page and open the module again: Continue from … goes on from the artifact where the run stopped.
- At first only inline styles are ticked in Settings. A removed tag such as
<b>leaves its text in place, and your choice is remembered in your browser.
What's new in version 3.46
· Change titles are published in English.
- The scope you pick stays
